产品描述
DESCRIPTION
PD (Powered Device) Integrated Module (Isolation Type)
FEATURES
l § Fully IEEE 802.3af compliant
l § 12 watt output load
l § IEEE Power class programmable (Green)
l § 1500 Volt DC isolation (Input to Output)
l § 5V, 12V DC output voltage models
l § Compact package minimum PCB footprint
l § Minimal external components required
l § Overload and short circuit protection
l § Wide input voltage (36V to 57V DC)
l § Adjustable output voltage
l § Support PoE applications in both of Fast / Gigabit Ethernet environments.
l § Low output ripple and noise
l § Low cost
APPLICATION AREAS
l § Security and alarm systems
l § Voice over IP phones
l § Access control systems
l § IP Cameras
l § Displays, Net Monitors
l § Public address systems
l § Wireless access points
l § Environmental control
l § Telemetry
l § Remote environmental monitoring
1 Product Overview
1.1 DP9800 Product Selector
Part Number | Nominal Output Voltage | Output Power(70˚C) |
DP9805M | 5.0V | 9 Watts |
DP9812M | 12.0V | 12 Watts |
2 Functional Description
2.1Typical Connections
